High-quality LPCB certified fire brigade connection (FDC), compliant with BS EN 14339. Ductile iron siamese inlet with check valve, ideal for fire sprinkler systems, commercial & industrial fire protection.
Technical Specification
| Item | Details |
|---|---|
| Product Name | Fire Brigade Connection (Fire Department Connection / Siamese Connection) |
| Standard | BS EN 14339 |
| Certification | LPCB Approved (Optional UL/FM) |
| Body Material | Ductile Iron / Cast Iron |
| Connection Size | DN65 (2.5") / DN80 (3") |
| Configuration | 2 Way / 3 Way / 4 Way Siamese |
| Valve Type | Integrated Check Valve, Optional Ball Valve |
| Pressure Rating | PN16 (16 Bar / 232 PSI) |
| Surface Treatment | Epoxy Powder Coated (Red / Custom Color) |
| Connection Type | Flanged End (ANSI / DIN / BS Standard) |
| Application | Fire Sprinkler Systems, Fire Hydrant Systems, Commercial & Industrial Buildings |
Emergency Fire Access Solution: Enables fire departments to quickly connect fire hoses to the building's fire sprinkler system, ensuring a reliable water supply for fire suppression.
Premium Ductile Iron Construction: High-strength ductile iron body delivers exceptional pressure resistance, impact durability and long service life, even in harsh outdoor environments.
Integrated Backflow Prevention: Built-in check valve prevents reverse flow of water, protecting the fire sprinkler system from contamination and ensuring system integrity.
Flexible Configuration Options: Available in 2-way, 3-way and 4-way siamese designs, compatible with standard DN65/DN80 fire hoses and couplings to meet different project requirements.
International Standard Compliance: Manufactured in full compliance with BS EN 14339 and other global fire safety standards, with LPCB/UL/FM certification available for global projects.
Easy Installation & Maintenance: Standard flanged end connections for simple, secure installation on fire protection pipelines, with optional ball valve for convenient system isolation during maintenance.
Corrosion-Resistant Design: Epoxy powder coated surface provides excellent corrosion and weather resistance, suitable for both indoor and outdoor installation.
Fire Brigade Connection (Fire Department Connection, FDC) is a critical component of fire protection systems, designed to provide fire departments with a dedicated, rapid access point to connect fire hoses and supply water to building fire sprinkler systems during emergencies. Manufactured to strict international fire safety standards, this siamese connection is the trusted choice for commercial buildings, industrial facilities, warehouses and public infrastructure worldwide.
